Plaques en Acier et Feuilles en Acier Steel Plates and Steel Sheets Acier Lachine Montreal Quebec En

Acier Lachine supplies hot laminated steel plates, floor plates or tread plates, steel sheets, and satin-coated and galvanized sheets in a variety of sizes and thicknesses to meet customers’ exact needs.

Additionally, Acier Lachine offers a large range of metal fabricating services involving steel plates and sheets, where their own metalworking professionals will cut, drill & punch, bend, shear, and weld the plates and sheets to clients’ requirements.

The Difference Between Steel Sheet and Steel Plate

Understanding the difference between sheet and plate will help you determine which type is best suited for your construction project.

In a nutshell, it is all about the thickness of the steel. Steel sheets are thicker than foil yet thinner than the plates. The thickness of a steel sheet is measured in terms of gauge. A higher gauge means thinner material, while a lower gauge means thicker, more durable steel. Often, steel plate is measured in inches whereas sheet metal is measured in gauges.

In precise terms, sheets thinner than 0.01″ (0.2mm) are considered foil or leaf, while pieces thicker than 0.25″ (6 mm) are considered steel plates or structural steel, also called flat steel.

Thickness of the Steel Plate
Thickness of the Steel Sheet
Thickness of the Foil

Explore our range of STEEL PLATES AND SHEETS

Please click any of the below sections and explore the wide range of the technical specifications of our steel sheets and plates inventory. In case you do not find the desired product or dimension of the existing one, please contact our representatives and they are going to find the products in the necessary dimensions for you.

plates

STEEL PLATES

plates

STEEL FLOOR PLATES

plates

STEEL SHEETS

plates

SATIN COATED AND GALVANIZED SHEETS

Browse all the Technical Specifications & Available Dimensions

Plaques en Acier et Feuilles en Acier | Steel Plates and Steel Sheets | Acier Lachine, Montreal, Quebec | www.acierlachine.com | +1-514-634-2252

STEEL PLATES

  • Construction Projects:

    • Building Structures:  Used in bridges, buildings, warehouses, airports, railway stations, and sports centers.

    • Foundations:   Strengthen building foundations and are integral to prefabricated homes.

  • Shipping Projects:

    • Containers:  Utilized for their rust and corrosion resistance, extending the lifespan of shipping containers.

  • Military Projects:

    • Vehicles and Equipment:  Steel plates are used in military applications for vehicles, ships, jets, jeeps, tanks, and protective buildings, providing essential strength and resistance to impacts and explosions.

  • Appliance Projects:

    • Home Appliances: Essential in manufacturing refrigerators, dishwashers, and other durable home appliances.

  • Automotive Projects:

    • Vehicle Manufacturing: Provide strength and safety in cars, improving fuel economy due to their lightweight nature.

  • Gas and Oil Pipeline Projects:

    • Pipeline Construction: Increase the durability and longevity of pipelines, protecting against corrosion and rust.

  • Road Work Projects:

    • Temporary Road Repairs: Used as a temporary fix over potholes and damaged roads, allowing for uninterrupted vehicle passage.

Steel Plates Info Table

wdt_ID Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
1 3/16″ 4.76 mm 7.66 lbs.
2 1/4″ 6.35 mm 10.21 lbs.
3 5/16″ 7.94 mm 12.76 lbs.
4 3/8″ 9.53 mm 15.31 lbs.
5 7/16″ 11.11 mm 17.87 lbs.
6 1/2″ 12.70 mm 20.42 lbs.
7 9/16″ 14.29 mm 22.97 lbs.
8 5/8″ 15.88 mm 25.52 lbs.
9 3/4″ 19.05 mm 30.63 lbs.
10 7/8″ 22.23 mm 35.73 lbs.
11 1″
12 1″ 25.40 mm 40.84 lbs.
13 1 1/8″ 28.58 mm 45.94 lbs.
14 1 1/4″ 31.75 mm 51.05 lbs.
15 1 3/8″ 34.93 mm 56.15 lbs.
16 1 1/2″ 38.10 mm 61.26 lbs.
17 1 5/8″ 41.28 mm 66.36 lbs.
18 1 1/2″ 38.10 mm 61.26 lbs.
19 1 5/8″ 41.28 mm 66.36 lbs.
20 1 3/4″ 44.45 mm 71.47 lbs.
21 1 7/8″ 47.63 mm 76.57 lbs.
22 2″
23 2″ 50.80 mm 81.68 lbs.
24 2 1/4″ 57.15 mm 91.89 lbs.
25 2 1/2″ 63.50 mm 102.10 lbs.
26 2 3/4″ 69.85 mm 112.31 lbs.
27 3″
28 3″ 76.20 mm 122.52 lbs.
29 3 1/4″ 82.55 mm 132.72 lbs.
30 3 1/2″ 88.90 mm 142.93 lbs.
31 3 3/4″ 95.25 mm 153.14 lbs.
32 4″
33 4″ 101.60 mm 163.35 lbs.
34 4 1/4″ 107.95 mm 173.56 lbs.
35 4 1/2″ 114.30 mm 183.77 lbs.
36 4 3/4″ 120.65 mm 193.98 lbs.
37 5″
38 5″ 127.00 mm 204.19 lbs.
39 5 1/4″ 133.35 mm 214.40 lbs.
40 5 1/2″ 139.70 mm 224.61 lbs.
41 5 3/4″ 146.05 mm 234.82 lbs.
42 6″
43 6″ 152.40 mm 245.03 lbs.
44 6 1/4″ 158.75 mm 255.24 lbs.
45 6 1/2″ 165.10 mm 265.45 lbs.
46 6 3/4″ 171.45 mm 275.66 lbs.
47 7″
48 7″ 177.80 mm 285.87 lbs.
49 7 1/4″ 184.15 mm 296.08 lbs.
50 7 1/2″ 190.50 mm 306.29 lbs.
51 7 3/4″ 196.85 mm 316.50 lbs.
52 8″
53 8″ 203.20 mm 326.71 lbs.
54 8 1/2″ 215.90 mm 347.13 lbs.
55 9″ 228.60 mm 367.55 lbs.
56 10″ 254.00 mm 408.38 lbs.
Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
Download the List of the Plates

Back-to-Top

Return to all Products

Browse all the Technical Specifications & Available Dimensions

Plaques en Acier et Feuilles en Acier | Steel Plates and Steel Sheets | Acier Lachine, Montreal, Quebec | www.acierlachine.com | +1-514-634-2252

STEEL FLOOR PLATES

Floor Plates

wdt_ID Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
1 14 Gauges 2.00 mm 3.750 lbs.
2 12 Gauges 2.80 mm 5.250 lbs.
3 1/8″ 3.20 mm 6.150 lbs.
4 3/16″ 4.80 mm 8.70 lbs.
5 1/4″ 6.00 mm 11.25 lbs.
6 5/16″ 8.00 mm 13.80 lbs.
7 3/8″ 10.00 mm 16.30 lbs.
8 1/2″ 12.00 mm 21.45 lbs.
Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
Download the List of the Plates

Back-to-Top

Return to all Products

Browse all the Technical Specifications & Available Dimensions

Plaques en Acier et Feuilles en Acier | Steel Plates and Steel Sheets | Acier Lachine, Montreal, Quebec | www.acierlachine.com | +1-514-634-2252

STEEL SHEETS

  • Construction:

    • Architectural Components:  Used in walls, floors, ceilings, and roofing for buildings, providing structural support and aesthetic finishes.

    • HVAC Systems:   Essential in ductwork and ventilation systems due to their flexibility and ease of installation.

  • Automotive:

    • Vehicle Bodies:  Widely used in manufacturing car bodies and components due to their strength and formability.

    • Truck Trailers:  Employed in constructing truck trailers for durability and weight management.

  • Industrial:

    • Machinery and Equipment:  Used in making industrial machinery and equipment, including storage tanks and agricultural machinery.

    • Fabrication: Essential for fabricating various industrial products and components.

  • Aerospace:

    • Aircraft Components: Utilized in making aircraft parts due to their lightweight and high-strength properties.

  • Household Appliances:

    • Appliances: Used in the production of home appliances like ovens, refrigerators, and washing machines for their durability and resistance to corrosion.

  • Decorative and Artistic:

    • Decorative Panels: Employed in creating decorative architectural elements and artistic installations.

Steel Sheets

wdt_ID Gauges Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
1 4 0.2242″ 5.695 mm 9.375 lbs.
2 5 0.2092″ 5.314 mm 8.750 lbs.
3 6 0.1943″ 4.935 mm 8.125 lbs.
4 7 0.1793″ 4.554 mm 7.500 lbs.
5 8 0.1644″ 4.176 mm 6.875 lbs.
6 9 0.1495″ 3.797 mm 6.250 lbs.
7 10 0.1345″ 3.416 mm 5.625 lbs.
8 11 0.1196″ 3.038 mm 5.000 lbs.
9 12 0.1046″ 2.657 mm 4.375 lbs.
10 13 0.0897″ 2.278 mm 3.750 lbs.
11 14 0.0747″ 1.897 mm 3.125 lbs.
12 15 0.0673″ 1.709 mm 2.812 lbs.
13 16 0.0598″ 1.519 mm 2.500 lbs.
14 17 0.0538″ 1.367 mm 2.250 lbs.
15 18 0.0478″ 1.214 mm 2.000 lbs.
16 19 0.0418″ 1.062 mm 1.750 lbs.
17 20 0.0359″ 0.912 mm 1.500 lbs.
18 21 0.0329″ 0.836 mm 1.375 lbs.
19 22 0.0299″ 0.759 mm 1.250 lbs.
20 23 0.0269″ 0.683 mm 1.125 lbs.
21 24 0.0239″ 0.607 mm 1.000 lbs.
22 25 0.0209″ 0.531 mm 0.875 lbs.
23 26 0.0179″ 0.455 mm 0.750 lbs.
24 27 0.0164″ 0.417 mm 0.688 lbs.
25 28 0.0149″ 0.378 mm 0.625 lbs.
26 29 0.0135″ 0.343 mm 0.562 lbs.
27 30 0.012″ 0.305 mm 0.500 lbs.
Gauges Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
Download the List of the Sheets

Back-to-Top

Return to all Products

Browse all the Technical Specifications & Available Dimensions

Plaques en Acier et Feuilles en Acier | Steel Plates and Steel Sheets | Acier Lachine, Montreal, Quebec | www.acierlachine.com | +1-514-634-2252

SATIN COATED AND GALVANIZED SHEETS

Satin Coated and Galvanized Sheets

wdt_ID Gauges Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
1 10 0.1382″ 3.51 mm 5.781 lbs.
2 11 0.1233″ 3.132 mm 5.156 lbs.
3 12 0.1084″ 2.753 mm 4.530 lbs.
4 14 0.0785″ 1.994 mm 3.281 lbs.
5 16 0.0635″ 1.613 mm 2.656 lbs.
6 18 0.0516″ 1.311 mm 2.156 lbs.
7 20 0.0396″ 1.006 mm 1.656 lbs.
8 22 0.0336″
9 24 0.0276″ 0.701 mm 1.156 lbs.
10 26 0.0217″ 0.551 mm 0.906 lbs.
11 28 0.0187″ 0.475 mm 0.781 lbs.
12 30 0.157″ 0.399 mm 0.656 lbs.
Gauges Thickness in Inches Thickness in MM Weight: Lbs./Sq.Ft.
Download the List of the Sheets

Back-to-Top

Return to all Products

An Overview of the Diversity of Steel Plates and Sheets at Acier Lachine

Plaques et Feuilles en Acier Steel Plates Sheets View 02
Plaques et Feuilles en Acier Steel Plates Sheets View 04
Plaques et Feuilles en Acier Steel Plates Sheets View 03
Plaques et Feuilles en Acier Steel Plates Sheets View 09
Plaques et Feuilles en Acier Steel Plates Sheets View 07
Plaques et Feuilles en Acier Steel Plates Sheets View 05
Plaques et Feuilles en Acier Steel Plates Sheets View 06
Plaques et Feuilles en Acier Steel Plates Sheets View 08
Plaques et Feuilles en Acier Steel Plates Sheets View 01
